- Size: 2200*760*1600
- Place of Origin: China
- Brand Name: zhongzan
- Model Number: lw6-8
- Weight: 620.000 kg
Model | LW-6 | LW-7 | LW-8 |
Max. Digging Depth (mm) | 1850 | 2150 | 2640 |
Max. Digging Radius (mm) | 2800 | 3360 | 3930 |
Max. Digging Height (mm) | 2500 | 3400 | 3510 |
Loading Height (mm) | 1400 | 1760 | 2000 |
Swing Arc (deg.) | 180 | 180 | 180 |
Bucket Rotation (deg.) | 160 | 160 | 160 |
Valve Standard Pressure | 16Mpa. | 16Mpa. | 16Mpa. |
Load Capacity (m3) | 0.036 | 0.045 | 0.054 |
Structural Weight (kg) | 620 | 650 | 680 |
Shipping Dimensions (mm) | 2200*760*1600 | 2200*780*1600 | 2200*800*1600 |
Bucket Width (mm) | 300 | 400 | 500 |
Power Required (hp) | 15-25 | 30-45 | 50-80 |
Max. Digging Length (mm) | 1410 | 1450 | 1610 |
Packing Method | Iron Crate | Iron Crate | Iron Crate |
